• MicroZed 7010: Zynq™-7000 SoC XC7Z010-1CLG400C
  • MicroZed 7020: Zynq™-7000 SoC XC7Z020-1CLG400C


Boot mode is determined by jumper headers labelled JP3, JP2 and JP1.

Boot mode JP3 JP2 JP1
JTAG (cascaded) 0 0 0
JTAG (independent) 0 0 1
Quad-SPI 1 0 X
SD Card 1 1 X


  • 0 = install jumper between pins 1 and 2
  • 1 = install jumper between pins 2 and 3
  • X = don’t care

Creating a custom AXI-Streaming IP in Vivado

The AXI-Streaming interface is important for designs that need to process a stream of data, such as samples coming from an ADC, or images coming from a camera. In this tutorial, we go through the steps to create a custom IP in Vivado with both a slave and master AXI-Streaming interface. The custom IP will be written in Verilog and it will simply buffer the incoming data at the slave interface and make it available at the master interface - in other words, it will be a FIFO. [Read More]

Using AXI DMA in Vivado Reloaded

The DMA is one of the most critical elements of any FPGA or high speed computing design. It allows data to be transferred from source to memory, and memory to consumer, in the most efficient manner and with minimal intervention from the processor. It’s no wonder then that a tutorial I wrote three years ago about using the AXI DMA IP, is still relevant and still getting thousands of visits per month. [Read More]

Using AXI Ethernet Subsystem and GMII-to-RGMII in a Multi-port Ethernet design

Tutorial Overview In this two-part tutorial, we’re going to create a multi-port Ethernet design in Vivado 2015.4 using both the GMII-to-RGMII and AXI Ethernet Subsystem IP cores. We’ll then test the design on hardware by running an echo server on lwIP. Our target hardware will be the ZedBoard armed with an Ethernet FMC, which adds 4 additional Gigabit Ethernet ports to our platform. Ports 0 to 2 of the Ethernet FMC will connect to separate AXI Ethernet Subsystem IPs which will be configured in DMA mode. [Read More]

Comparison of Zynq SoMs

Comparison of Zynq SoMs
In the last year or so, there has been an explosion in the availability of System-on-Modules (SoMs) featuring the popular FPGA+ARM combo Zynq-7000 SoC from Xilinx. I’ve always promoted the idea that FPGAs and SoCs allow for faster design cycles and rapid proof-of-concept, but these SoMs take that advantage to another level. Let me explain why. In the past, I would handle most projects by doing a proof-of-concept on an evaluation board, then designing a custom board that integrates all the required components onto a single PCB. [Read More]

Using the AXI DMA in Vivado

Using the AXI DMA in Vivado
Update 2017-10-10: I’ve turned this tutorial into a video here for Vivado 2017.2. In a previous tutorial I went through how to use the AXI DMA Engine in EDK, now I’ll show you how to use the AXI DMA in Vivado. We’ll create the hardware design in Vivado, then write a software application in the Xilinx SDK and test it on the MicroZed board (source code is shared on Github for the MicroZed and the ZedBoard, see links at the bottom). [Read More]
dma  popular

Creating a custom IP block in Vivado

Creating a custom IP block in Vivado
Update 2017-11-01: Here’s a newer tutorial on creating a custom IP with AXI-Streaming interfaces Tutorial Overview In this tutorial we’ll create a custom AXI IP block in Vivado and modify its functionality by integrating custom VHDL code. We’ll be using the Zynq SoC and the MicroZed as a hardware platform. For simplicity, our custom IP will be a multiplier which our processor will be able to access through register reads and writes over an AXI bus. [Read More]

Creating a Base System for the Zynq in Vivado

Creating a Base System for the Zynq in Vivado
Tutorial Overview In the ISE/EDK tools, we’d use the Base System Builder to generate a base project for a particular hardware platform. Now with Vivado, the process is a little different but we have more control in how things are setup and we still benefit from some powerful automation features. In this tutorial we’ll create a base design for the Zynq in Vivado and we’ll use the MicroZed board as the hardware platform. [Read More]

Comparison of Zynq boards

If you’re interested in testing out the Zynq-7000 SoC from Xilinx there are now quite a few options available, so it comes down to a question of features vs price. Below I’ve listed the most important features of the available boards side-by-side to help you make the right decision for yourself or your company. I’ll also go into what I think of each board before we look at the boards in terms of their popularity. [Read More]
